12 Ton Hydraulic Truck Crane XCT12L4-1 XCT12L5 Euro 5/6 Engine
Product Introduction
New 12 Ton Small Hydraulic Truck Crane featuring Euro 5/Euro 6 engine, available in XCT12L4-1 and XCT12L5 models, ideal for versatile lifting operations.
Key Specifications
| Max Lifting Capacity | 12 Ton |
| Engine Standard | Euro 5 / Euro 6 |
| Model Options | XCT12L4-1, XCT12L5 |
| Type | Small Hydraulic Truck Crane |
New 12 Ton Small Hydraulic Truck Crane XCT12L4 with Euro 5/6 Engine
Experience superior lifting performance with the XCT12L4 Truck Crane, engineered for efficiency and reliability in diverse construction environments. This 12-ton small hydraulic truck crane combines advanced technology with robust design, making it ideal for both urban and industrial applications.
Core Specifications
| Parameter | Value |
|---|---|
| Max. Lifting Capacity | 12 t |
| Main Boom Length | 30.9 m |
| Engine Power | 162-170 kW |
| Max. Travel Speed | 90 km/h |
| Total Weight | 16,000 kg |
| Min. Stable Slewing Speed | 0.1¡ã/s |
| Max. Gradeability | 41% |
| Overall Dimensions (L¡ÁW¡ÁH) | 10900¡Á2500¡Á3550 mm |
| Fuel Consumption | 25 L/100km |
| Max. Lifting Torque | 482.5 kN.m |
Key Features
- Superior Lifting Performance: 32m 4-section boom with eight-side profile, offering 10% higher load capacity than competitors.
- Energy-Saving Hydraulics: Precise control with 0.1¡ã/s slewing speed and 2.5m/min lifting speed for safe operations.
- Powerful Engine Options: Euro 5/Euro 6 compliant Weichai/Shanghai diesel engines for optimal fuel efficiency.
- Enhanced Maneuverability: 90 km/h max speed and 41% gradeability for easy transportation across job sites.
- Durable Design: Heavy-duty construction with 16,000 kg total weight ensures stability in tough conditions.
Applications
Perfect for construction sites, urban renewal projects, ports, bridges, oilfields, and mines. Its compact size and high performance make it suitable for both simple and complex working environments.
Why Choose XCT12L4?
Compared toͬÀà²úÆ·, the XCT12L4 stands out with its longer boom, lower fuel consumption (10% less than average), and superior torque output. The advanced power transmission system ensures a perfect balance of power and efficiency, reducing operational costs.
FAQ
- What is the maximum boom length? 30.9m main boom; 38.1m with jib.
- Is the crane suitable for rough terrain? Yes, with 250mm ground clearance and 41% gradeability.
- What engine options are available? Weichai/Shanghai Nation V/III diesel engines (162-170 kW).
- What is the turning radius? 18m min. turning diameter for easy maneuvering.
Ready to elevate your project efficiency? Contact us today for a personalized quote and technical support!
