Diesel Concrete Trailer Pump HBT9028CH-5S for Sale
Product Introduction
Trailer Pump HBT9028CH-5S Diesel Pump Concrete Machinery with advanced hydraulic system, intelligent control, and energy-saving technology, offering efficient concrete pumping performance.
Technical Parameters
| Max. Concrete Output | 95/70 m3/h |
| Max. Delivery Pressure | 19/28 Mpa |
| Power | 2x180kW |
| Dimension (L*W*H) | 7508¡Á2272¡Á2750 mm |
| Gross Weight | 11910 kg |
Trailer Pump HBT9028CH-5S Diesel Concrete Pump: High-Performance Machinery for Efficient Construction
Boost your construction projects with the HBT9028CH-5S Diesel Trailer Pump, engineered for maximum productivity and reliability. This advanced concrete machinery combines cutting-edge hydraulic technology with intelligent controls, delivering exceptional performance for large-scale building operations. Whether you’re working on high-rise construction, bridges, or industrial facilities, this pump ensures precise concrete placement with minimal fuel consumption.
Core Specifications
| Power | 2x180kW |
| Max. Delivery Pressure | 19/28 Mpa (Low/High) |
| Max. Concrete Output | 95/70 m3/h (Low/High) |
| Delivery Cylinder | ¦µ200¡Á2100 mm |
| Hopper Capacity | 0.7 m3 |
| Feeding Height | 1420 mm |
| Dimensions | 7508¡Á2272¡Á2750 mm |
| Gross Weight | 11910 kg |
| Aggregate Size (¦µ150mm Pipe) | 50 mm |
| Aggregate Size (¦µ125mm Pipe) | 40 mm |
Key Advantages
- Advanced Hydraulic System: Differential pressure control and bi-directional design ensure smooth operation and high efficiency
- Intelligent Controls: Fault self-diagnosis and emergency override for enhanced safety and uptime
- Energy-Saving Technology: Auto-adjusts engine power to reduce fuel consumption by up to 25%
- Wear-Resistant Components: Sino-Germany materials extend service life in harsh conditions
- High-Power Mixing Motor: Ensures consistent concrete quality during pumping
Applications
Ideal for commercial construction, infrastructure projects, and industrial concrete placement. Perfect for high-pressure vertical pumping in skyscrapers or long-distance horizontalÊäËÍ on highway projects.
Performance Highlights
The HBT9028CH-5S delivers exceptional output with precise pressure control, making it suitable for both low and high-pressure applications. Its large bore reversing cylinder and new-type hopper design minimize blockages and maximize material flow.
Quality Assurance
Built with premium components and rigorous testing, this pump meets international quality standards. The G5 improved wearing parts ensure durability even in continuous operation.
Why Choose Our Diesel Pump?
Compared to competitors, our pump offers superior fuel efficiency, faster maintenance, and higher reliability. The integrated motion controller and automatic piston retraction system reduce operator workload and increase productivity.
FAQ
Q: What maintenance is required?
A: Regular oil checks and filter replacements; wear parts should be inspected monthly during heavy use.
Q: Can it handle harsh weather?
A: Yes, the robust design performs in extreme temperatures and dusty environments.
Q: Is training available?
A: We provide operational manuals and online support for proper setup and use.
Ready to enhance your construction efficiency? Contact us today for pricing and technical details on the HBT9028CH-5S Diesel Trailer Pump.
