HBT6013V 60m3/h Diesel Concrete Stationary Pump Sale
Product Introduction
HBT6013V trailer concrete pump is a modern construction equipment for continuous concrete pouring, featuring high reliability, easy maintenance and low cost with advanced technologies like efficient skirt valve pumping system and energy-saving control.
Key Parameters
| Model | HBT6013V |
| Concrete Delivery Capacity | 65/40 m3/h |
| Maximum Output Pressure | 13 Mpa |
| Conveying Distance (Vertical/Horizontal) | 150/600 m |
| Rated Power | 118 kw |
Xuzhou Factory New 60m3/h Diesel Concrete Stationary Pump HBT6013V – High-Efficiency Construction Solution
Designed for continuous concrete pouring, the HBT6013V stationary pump delivers unparalleled reliability, easy maintenance, and cost-effectiveness. Ideal for large-scale construction projects, this diesel-powered pump combines advanced technology with robust performance to boost your productivity.
Core Specifications
| Model | HBT6013V |
| Concrete Delivery Capacity | 65/40 m3/h |
| Max Output Pressure | 13 Mpa |
| Conveying Distance (Vertical/Horizontal) | 150/600 m |
| Rated Power | 118 kw |
| Machine Weight | 6900 kg |
| Dimensions | 6115¡Á2100¡Á2810 mm |
| Concrete Slump Range | 80-230 mm |
| Hopper Capacity/Loading Height | 0.6 m3 / 1400 mm |
| Manufacturer (Engine) | Weichai |
Key Advantages
- Efficient skirt valve pumping system for smooth concrete flow
- Stable commutation buffer technology reduces operational noise
- Full hydraulic reversing technology ensures reliable performance
- Energy-saving control system lowers fuel consumption
- Smart electrical control with safety protection features
- Ergonomic design for easy maintenance access
Application Scenarios
Perfect for high-rise building construction, bridge projects, residential complexes, and industrial facilities. Its powerful vertical (150m) and horizontal (600m) conveying capabilities make it suitable for both urban and remote construction sites.
Performance Highlights
Equipped with a Weichai diesel engine and Rexroth A11VLO130 main pump, the HBT6013V delivers consistent performance even under heavy loads. The 400L hydraulic oil tank ensures efficient cooling, while the open hydraulic system guarantees smooth operation.
Quality Assurance
Manufactured in Xuzhou factory with strict quality control standards. All components undergo rigorous testing to ensure durability and long service life. Backed by professional technical support and after-sales service.
FAQ
Q: What is the minimum concrete slump required?
A: 80mm (suitable for most standard concrete mixes)
Q: How often is maintenance required?
A: Routine checks every 500 operating hours; major service every 2000 hours.
Q: Can it handle aggregate sizes up to?
A: Optimal for aggregates ¡Ü40mm in diameter.
Ready to enhance your construction efficiency? Contact us now for a personalized quote and technical specifications!
