Zrt600e532 60t 5-Section Boom Rough Terrain Crane
Product Introduction
The Zrt600e532 is a 60t rough terrain crane with a 5-section boom, ideal for narrow job sites. It features four-wheel drive, four-wheel steering, and excellent off-road capability, ensuring high maneuverability and efficiency in various conditions.
Key Specifications
| Max. Rated Lifting Capacity | 60t¡Á3.0m |
| Main Boom Length | 11.6-45m |
| Max. Lifting Height | 61.2m |
| Max. Driving Speed | 40/37 km/h |
| Gross Weight | 45000 kg |
Zrt600e532 60t Rough Terrain Crane: Power & Precision for Heavy-Duty Operations
Engineered for challenging job sites, the Zrt600e532 60t Rough Terrain Crane combines robust performance with exceptional maneuverability. Its 5-section boom and advanced 4×4 drive system make it ideal for construction, mining, and infrastructure projects in Argentina and beyond. With a maximum lifting capacity of 60,000 kg at 3.0m radius and a main boom length of 11.6-45m, this crane delivers unmatched efficiency in tight spaces.
Core Specifications
| Parameter | Value |
|---|---|
| Max. Lifting Capacity ¡Á Radius | 60000kg¡Á3.0m |
| Main Boom Length | 11600-45000mm |
| Max. Lifting Height (Main Boom) | 45.1m |
| Drive System | Four-wheel drive & steer |
| Max. Driving Speed | 40/37 km/h |
| Gradeability | 75% |
| Hoist Rope Speed (Main Winch) | 130 m/min |
| Overall Dimensions | 14100¡Á3300¡Á3790mm |
| Outrigger Spread | 7380¡Á7400mm |
| Gross Weight | 45000kg |
Key Features & Benefits
- Superior Maneuverability: Four-wheel steering modes (front, four-wheel, crab) and compact turning radius for narrow sites.
- Off-Road Dominance: High ground clearance and specialized tires tackle rough terrain effortlessly.
- Pick-and-Carry Efficiency: Lift loads without extending outriggers, boosting on-site productivity.
- Single Cab Comfort: Air-cushioned seat, AC, and digital displays reduce operator fatigue during long shifts.
- 360¡ã Unlimited Swing: Full-range rotation ensures precise load placement in any direction.
Applications
Perfect for construction sites, oil fields, mining operations, and infrastructure development. Its versatility shines in remote locations where terrain and space are constraints, delivering reliable performance for heavy lifting tasks.
Why Choose Zrt600e532?
Unlike standard cranes, this model integrates electronically-controlled engine technology with hydraulic suspension, ensuring consistent power output even under sudden resistance. The combination of speed (130m/min hoist) and durability makes it a top choice for time-sensitive projects.
Quality Assurance
Manufactured by Maxizm Construction Machinery, a leader with 12+ years of exporting experience. Each unit undergoes rigorous testing to meet international safety standards, backed by responsive after-sales support.
FAQ
- What steering modes are available? Front-wheel, four-wheel, and crab steer for maximum flexibility.
- Can it operate without outriggers? Yes, supports “On tires” lifts for tight spaces.
- What is the jib length range? 9500-16000mm, extending max lifting height to 61.2m.
- Is it suitable for all-weather use? Equipped with air conditioning for year-round operation.
Ready to elevate your project efficiency? Contact our sales team today for a personalized quote and technical details.
